Product Introduct                                     Hydraulic grouting pump is widely used in the pumping and pressure grouting of cement slurry, yellow mud, water glass, oil and water, etc. It can pump two kinds of media at the same time, and can also pump a single medium, suitable for various construction projects. , municipal engineering, tunnel engineering, mines, oil, etc. Parameters                                            Product Display                                             1. Dual-cylinder double-acting, the piston reciprocates once, can implement two kinds of liquid suction and discharge. 3, Compact structure, suitable for small space implementation, unique mechanical reversing mechanism, and then special workplaces can also be used. (with explosion-proof function)  Working                                             Gear oil pump is directly driven by the motor , the oil pump pressure oil output into the manifold, the overflow valve (adjust the working pressure of the system) into the electro-hydraulic reversing valve, by the electro-hydraulic reversing valve and the proximity switch, the joint realization of the cylinder to reciprocate . Henan Yugong Machinery Co.,Ltd. is specialized in machinery in China over 20 years. We are committed to researching and developing all kinds of construction machinery  etc. Our company has more than 500 employees,including more than 30 senior technical staff and 30 international sales persons.We can supply high quality and professional services. Henan Yugong Machinery Co., Ltd aims to have top quality, top reputation and top service. "Quality First, Reputation First, Be Innovative, Be Excellent" has always been our purpose. We warmly welcome your corporation from all fields and build great future for us. Product Introduct                                     Hydraulic grouting pump is widely used in the pumping and pressure grouting of cement slurry, yellow mud, water glass, oil and water, etc. It can pump two kinds of media at the same time, and can also pump a single medium, suitable for various construction projects. , municipal engineering, tunnel engineering, mines, oil, etc. Parameters                                            Product Display                                             1. Dual-cylinder double-acting, the piston reciprocates once, can implement two kinds of liquid suction and discharge. 3, Compact structure, suitable for small space implementation, unique mechanical reversing mechanism, and then special workplaces can also be used. (with explosion-proof function)  Working                                             Gear oil pump is directly driven by the motor , the oil pump pressure oil output into the manifold, the overflow valve (adjust the working pressure of the system) into the electro-hydraulic reversing valve, by the electro-hydraulic reversing valve and the proximity switch, the joint realization of the cylinder to reciprocate . Henan Yugong Machinery Co.,Ltd. is specialized in machinery in China over 20 years. We are committed to researching and developing all kinds of construction machinery  etc. Our company has more than 500 employees,including more than 30 senior technical staff and 30 international sales persons.We can supply high quality and professional services. Henan Yugong Machinery Co., Ltd aims to have top quality, top reputation and top service. "Quality First, Reputation First, Be Innovative, Be Excellent" has always been our purpose. We warmly welcome your corporation from all fields and build great future for us.
Flexible Packaging Film
Describe:
1) The roll films are suitable for auto-packinhg machines with different film specifications.
2) Wide using range on packing many kinds of products, such as ketchup, honey, chill souce,cosmetic items,paste,biscuits, snackfood,chips, cookies,cakes, bread, coffee,milk powder, chilli peper, candies, hotdogs, fast food and so on.
3) With vivid and sharp printing effect.
4) Per roll be packed with air bubble on pallet or as customer`s requirement.
Flexible Packaging Film show:
Bopp Cigarette Fim,Bopp Pearlized Film,Bopp Label Film,Anti Fog Bopp Film Shijiazhuang dadao Packaging materials Co , https://www.ddplasticfilm.com

Â
Hydraulic Grout Pump
Model
YG-GP80
YG-GP110
Max. Flow
80 L/min
110 L/min
Grouting Capacity
4 m3/h
Grouting Pressure
0.5-7 Mpa (Max. 10 Mpa)
Convey Distance
Horizontal  100-200 m
Vertical  50-70 m
Power
7.5/11/15 KW
Suction Pipe Inside Dia.
∅51 *2
Grouting Suction Pipe Inside Dia.
∅32
∅38
Outlet Pipe Dia.
∅25 *2
Dimensions
1200*800*1000 mm
Weight
600 kg
2, Hydraulic drive, reliable work, high pumping pressure.
When the cylinder moves forward and pushes the material cylinder, rod chamber of the material cylinder forms a vacuum, and the suction chamber of the rod chamber sucks the slurry through a suction filter; at the same time, the rodless chamber of the material cylinder grout through the discharge valve chamber and the mixer and grouting valve. Conversely, when the cylinder moves backwards, the material cylinder sucks the slurry in the rodless chamber and discharges the slurry in the rod chamber. The two chambers of the material cylinder can suck and discharge the same slurry, and can also suck and discharge two different kinds of slurry.
Contact Us                                         Â

Â
Â
Hydraulic Grout Pump
Model
YG-GP80
YG-GP110
Max. Flow
80 L/min
110 L/min
Grouting Capacity
4 m3/h
Grouting Pressure
0.5-7 Mpa (Max. 10 Mpa)
Convey Distance
Horizontal  100-200 m
Vertical  50-70 m
Power
7.5/11/15 KW
Suction Pipe Inside Dia.
∅51 *2
Grouting Suction Pipe Inside Dia.
∅32
∅38
Outlet Pipe Dia.
∅25 *2
Dimensions
1200*800*1000 mm
Weight
600 kg
2, Hydraulic drive, reliable work, high pumping pressure.
When the cylinder moves forward and pushes the material cylinder, rod chamber of the material cylinder forms a vacuum, and the suction chamber of the rod chamber sucks the slurry through a suction filter; at the same time, the rodless chamber of the material cylinder grout through the discharge valve chamber and the mixer and grouting valve. Conversely, when the cylinder moves backwards, the material cylinder sucks the slurry in the rodless chamber and discharges the slurry in the rod chamber. The two chambers of the material cylinder can suck and discharge the same slurry, and can also suck and discharge two different kinds of slurry.
Contact Us                                         Â
Â
Bridge Grouting Bridge Grouting Pump Manufacturer
Model NO.: Yg-Gp80
Certification: ISO9001: 2000, CE
Condition: New
Color: White
Product Name: Hydraulic Grout Pump
Application: Mortar Grouting
Model: Yg-Gp80
Max. Flow: 80 L/Min
Grouting Capacity: 4 M3/H
Grouting Pressure: 0.5-7 MPa
Convey Distance: Horizontal 100-200 M, Vertical 50-70 M
Power: 7.5/11/15 Kw
Suction Pipe Inside Dia.: 51 mm *2
Dimensions: 1200*800*1000 mm
Trademark: YUGONG
Transport Package: Standard Wooden Case.
Specification: 380V three-phase 50Hz
Origin: China
HS Code: 8413503190
Model NO.: Yg-Gp80
Certification: ISO9001: 2000, CE
Condition: New
Color: White
Product Name: Hydraulic Grout Pump
Application: Mortar Grouting
Model: Yg-Gp80
Max. Flow: 80 L/Min
Grouting Capacity: 4 M3/H
Grouting Pressure: 0.5-7 MPa
Convey Distance: Horizontal 100-200 M, Vertical 50-70 M
Power: 7.5/11/15 Kw
Suction Pipe Inside Dia.: 51 mm *2
Dimensions: 1200*800*1000 mm
Trademark: YUGONG
Transport Package: Standard Wooden Case.
Specification: 380V three-phase 50Hz
Origin: China
HS Code: 8413503190
Double Cylinder High Pressure Hydraulic Grout Pump
